Product Description:
Technical Parameters:
| CHARACTERISTICS |
| Model |
SLDR450 |
| Power unit |
Diesel |
| Operation type |
Driver seated |
| Load capacity (L1, L2, L3) |
Q (kg) |
45000/31000/16000 |
| Load centre, first row (L1) |
c (mm) |
1800 |
| Load centre, second row (L2) |
C (mm) |
3860 |
| Load centre, third row (L3) |
C (mm) |
6400 |
| Axle centre to spreader center (L1-1/2 high) |
x (mm) |
2800 |
| Wheelbase |
y (mm) |
6400 |
| DIMENSIONS |
| Boom lift angle, raise/lowered |
α/β(/°) |
61/0 |
| Height boom lowered |
h1 (mm) |
4945 |
| Lift height (L1, L2, L3) |
h3 (mm) |
15900/14100/11350 |
| Height, boom extended |
h4 (mm) |
19000 |
| Height of cabin |
h6 (mm) |
3900 |
| Height, operator's seat |
h7 (mm) |
2840 |
| Towing coupling height |
h10 (mm) |
600 |
| Twist lock height lowered |
h13 (mm) |
1495 |
| Overall length with spreader |
l1 (mm) |
11618 |
| Overall length |
l2 (mm) |
8410 |
| Overall width |
b1/b2 (mm) |
4180/3400 |
| Width of spreader 20'/40' |
b3 (mm) |
6050/12150 |
| Ground clearance min. |
m1 (mm) |
345 |
| Ground clearance, centre of wheelbase |
m2 (mm) |
350 |
| Stacking aisle 20' containers |
Ast (mm) |
10225 |
| Stacking aisle 40' containersTurning radius |
Ast (mm) |
13050 |
| Min. pivoting point distance |
Wa (mm) |
8605 |
| Min. pivoting point distance |
b13 (mm) |
3400 |
| Wheelspan, front wheels |
b10 (mm) |
3030 |
| Wheelspan, rear wheel |
b11 (mm) |
2786 |
| WEIGHT |
| Weight (unladen/laden) |
kg |
71400/116400 |
| Load on drive axle (unladen/laden) |
kg |
36400/101900 |
| Load on steering axle (unladen/laden) |
kg |
35000/14500 |
| PERFORMANCE |
| Travelling speed (unladen/laden) |
Km/h |
25/21 |
| Gradeability (unladen/laden) |
% |
30/28.8 |
| Tractive force (unladen) |
Kn |
408 |
| Lifting speed (unladen/laden) |
m/s |
0.39/0.28 |
| Lowering speed (unladen/laden) |
m/s |
0.39/0.39 |
| CABIN |
| Movable closed cabin |
| Equipped with A/C, cooling/heating functions |
| Noise level at driver's seat |
dBA |
74 |
| ENGINE |
| Brand |
|
CUMMINS |
| Type |
|
QSM11 |
| Cylinder no./displacement |
|
6/10820 cm3 |
| Rated power @ rated speed |
|
250kw @ 2100rpm |
| Max. torque |
|
1674Nm@ 1500rpm |
| Rated current of alternator |
|
150A |
| Battery |
|
24V |
| TRANSMISSION |
| Brand |
|
ZF/5WG261 AUTO |
| Type |
|
Auto-shift/interlock |
| Clutch type |
|
Torque converter |
| Gear no. |
|
5F/3R |
| TYRES |
| Drive wheels |
|
18.00-25 40PR |
| Steering wheels |
|
18.00-25 40PR |
| Type |
|
Pneumatic |
| Pressure |
|
10 bar |
| Quantity, front/rear |
|
4/2 |
| TANKS CAPACITY |
| Hydraulic oil tank |
L |
800 |
| Fuel tank |
L |
500 |
| DRIVE AXLE |
| Brand |
|
Kessler/Germany |
| Model |
|
D102PL341 |
| STEERING AXLE |
| Brand |
|
Kessler/Germany |
| Model |
|
L102 |
| Steering |
|
Double action cylinder |
| BRAKE SYSTEM |
| Service brake |
|
Hydraulic wet-disc |
| Parking brake |
|
Electric released disc brake, enabled when power off |
| HYDRAULIC SYSTEM |
| Twin piston pump |
| Max. pressure: 310 bar |
| Load sensing system |
| Hydraulic cooler with electric motor |
| Separate brake oil tank |
| BOOM |
| 2x Dual action lift cylinders |
| 1x Dual action extension cylinder |
| SPREADER |
| Handling ISO 20'-40' containers |
| 2x damping cylinder |
2x gearbox & brake system |
| Brand |
SP45 |
| Rotate degrees |
-105°/+195° |
| Sideshift |
-800/+800mm |
| TRUCK SAFETIES |
| Error display system |
| Counter system for containers |
| Weighing system (low precision) |
| Electric anti-overload system |
| Full can-bus control system |
| Direction gearshift interlock |
| Parking brake enabled when power off |
| Seat switch |
| SPREADER SAFETIES |
| Locking/unlocking only after correct landing |
| Lifting/lowering only when the 4 twistlocks on same position |
| Anticollision rotation limit switch |
|
Applications:
Empty Container Handler – Your Solution for Efficient Container Management
Empty Container Handler is a quality product designed and produced by SLD, a leading brand in China known for its reliable and efficient handling equipment. This innovative machine is perfect for handling ISO 20'-40' containers, making it an essential tool for container depots, container terminals, and logistics companies.
Product Features
- Brand Name: SLD
- Place of Origin: China
- Certification: ISO, CE
- Minimum Order Quantity: 1 unit
- Price: Negotiable price USD 0.08-0.15/Piece
- Packaging Details: Nude
- Delivery Time: 30 working days
- Payment Terms: L/C, T/T
- Supply Ability: 10 units per month
- Spreader Type: Handling ISO 20'-40' Containers
- Color: Red
- Performance: Quality Product
- Drive Axle: Kessler D102PL341
- Transmission: ZF 5WG261 AUTO
Product Description
The Empty Container Handler is a specialized handling equipment used for managing vacant containers in container depots, container terminals, and logistics companies. It is designed to improve efficiency and reduce manual labor in the container handling process.
Equipped with a powerful drive axle and transmission, this machine can easily lift and transport ISO 20'-40' containers with ease. Its spreader type is specifically designed for handling these containers, making it a perfect fit for the job.
Application and Scenario
The Empty Container Handler is an essential tool for any facility or company involved in container management. Its main application is in container depots, where it is used to organize and store empty containers. With this machine, container depots can efficiently manage their inventory and easily retrieve containers when needed.
Container terminals also benefit greatly from this product as it helps in the smooth flow of containers. By using the Empty Container Handler, containers can be quickly moved from one location to another, reducing waiting times and improving overall efficiency.
Logistics companies also find this product useful in their daily operations. With the ability to handle containers of different sizes, the Empty Container Handler can easily transfer containers from trucks to storage areas, making the logistics process more efficient.
Product Benefits
- Vacant Container Management: The Empty Container Handler helps in organizing and managing vacant containers, making it easier to locate and retrieve them when needed.
- Container Voiding Facility: It provides a safe and efficient way to empty containers of any remaining cargo or debris before storage or transportation.
- Empty Container Disposal System: This machine can also be used for disposing of empty containers that are no longer in use, freeing up space and improving overall efficiency.
- Improved Efficiency: With the use of the Empty Container Handler, manual labor is significantly reduced, and the container handling process is more efficient.
- Cost-Effective: This product eliminates the need for additional labor and reduces waiting times, ultimately leading to cost savings for the company.
Investing in the Empty Container Handler from SLD means investing in a quality product that will improve your container management process and increase efficiency. With its powerful performance and reliable brand, it is a valuable asset for any facility or company involved in handling containers. So why wait? Get your Empty Container Handler today and experience the difference it can make in your operations!
Customization:
SLD Empty Container Handler Customized Service
Brand Name: SLD
Place of Origin: China
Certification: ISO, CE
Minimum Order Quantity: 1 unit
Price: Negotiable price USD 0.08-0.15/Piece
Packaging Details: Nude
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 10 units per month
Warranty: 1 Year
Service Weight: 71400 Kgs (unload)
Color: Red
New Or Used: New
Transmission: ZF 5WG261 AUTO
Customized Services:
- Container Emptying System: We offer customized container emptying systems to efficiently and safely empty containers of various sizes and types.
- Container Voiding Facility: Our container voiding facilities are designed to quickly and effectively remove any remaining residue from emptied containers.
- Container Emptying System Maintenance: We provide regular maintenance services to ensure optimal performance and longevity of your container emptying system.
- Container Emptying System Repair: In case of any malfunctions or breakdowns, our team of experts is available to provide prompt and reliable repair services for your container emptying system.
